    Product Details:

    Place of Origin: China
    Brand Name: Saint Best
    Certification: CE/ISO
    Model Number: SBT-LJZ2-450x3700

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Set
    Price: Negotiable
    Packaging Details: Customized
    Delivery Time: 5-10days
    Payment Terms: T/T;Western Union;Paypal
    Supply Ability: 48Sets/Month
    Contact Now
    Detailed Product Description

    Basic Info
    • Model NO.: SBT-LJZ2-450x3700
    • Export Markets: Global
    Additional Info
    • Trademark: Saint Best
    • Packing: Wooden
    • Standard: CE
    • Origin: China
    • HS Code: 84778000
    • Production Capacity: 1000/Year
    Product Description

    Function
    For 45° ~90° Plastic and aluminum profile cutting.
    Features:
    Equipped with cutting angle fine adjustment device.
    Straight line feeding type; The guide for machine body and feeding system adopt linear bearing system to ensure stable feeding and high cutting precision.
    Optional: Machine head could adopt air-hydraulic damping cylinder to cut aluminum profile.
    Same shaft angle-changing structure for good surface cutting performance.
    Profile supporter is available on the movable head.
    One time two pieces of profile cutting (height of profile less then 60mm).
    With short profile cutting device on left machine head can realize super short profile cutting.
    Manual type.
    Parameter:
    Air Pressure: 0.5MPa~0.8MPa
    Air Consumption: 50L/min
    Input Voltage: 380V 50Hz
    Input Power: 5.25KW
    Spindle Rotary Speed: 2800r/min
    Cutting Length Range: 290mm~3700mm
    Cutting Width: 120mm
    Cutting Height: 90° 200mm; 45° 165mm
    Overall Dimension: 6000mmx1300mmx1650mm
    Weight: 1200kg
    Overall Dimension: 4600mmx1250mmx1800mm
    Weight: 600kg
