Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing

Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing

    • Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing
    • Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing
    • Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing
    • Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing
    • Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing
    • Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing
  • Single Side Cold Press Machine for Super Spacer Insulating Glass / Double Glazing

    Product Details:

    Place of Origin: China
    Brand Name: Saint Best
    Certification: Valid
    Model Number: SBT-SSHP98

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Set
    Price: Send email
    Packaging Details: Customized
    Delivery Time: 10~15days
    Payment Terms: T/T;Western Union;Paypal;Alipay
    Supply Ability: 48Sets/Month
    Contact Now
    Detailed Product Description

    Single Side Cold Press Table for Super Spacer Insulating Glass / Double Glazing



    Product Details:



    Place of Origin: China
    Brand Name: Saint Best
    Certification: Valid
    Model Number: SBT-SSHP98

    Payment & Shipping Terms:



    Minimum Order Quantity: 1 Set
    Price: Negotiable
    Packaging Details: Standard Export Package/Carton
    Delivery Time: 10~20Days
    Payment Terms: T/T, Western Union, MoneyGram,Paypal,Alipay
    Supply Ability: 18Sets/Month

    Detailed Product Description



    Machine: Single Side Cold Roller Press Table For Super Spacer Insulating Glass / Double Glazing Model: SBT-SSHP98
    Application: Insulating Glass / Double Glazing Single Side Heated Roller Press Max IGU Size: 1000mm
    Glass Thicknes: 30mm Rollers: 6 Pairs


    Single Side Cold Roller Press for Super  Spacer Insulating Glass / Double Glazing

    Quick Details

    • Place of Origin: China (Mainland)
    • Brand Name: SAINT BEST
    • Model Number: SBT-SSHP98
    • After-sales Service Provided: Engineers available to service machinery overseas
    • Voltage: 380V 50Hz
    • Power: 10kw
    • Max. Glass Width:1000mm
    • IGU thickness: 30mm
    • Washing speed: 2m/min

    Packaging & Delivery

    Packaging Details: Standard Export Package or according to customers' demands.
    Delivery Detail: 15days


    I. Working Principle

    1. Driven system

      A motor equipped with a speed controller is applied in the complete appliance, and the speed can be

     adjusted by chain diver.

    2. Heating system:

    Four far infrared U-tubes are used in this machine to heat the glass from the directions of

     both the top and the bottom, and it is possible to adjust the temperature automatically.

    3. Rolling system

     There are six pairs of high-temperature resistance rubber roller to press and laminate the glass

     after the pieces are put together.An adjusting device with numeric display is deployed to show the

     thickness.The space between the upper and lower rubber rollers is adjusted with the

    maximum laminating thickness is 30mm

    Single Side Cold Press Table for Super Spacer Insulating Glass / Double Glazing

    II. Technical Parameters

    Maximum breadth of the laminating glass

    ≤1000mm

    Minimum size of the laminating glass

    200×200mm

    Maximum transmission speed

    2m/min

    Thickness of the hollow glass

    10-30mm

    Maximum rising distance of the upper rubber roll

    30mm

    Motor power

    0.25KW  380V

    Speed regulation range of the machine

    5-10r/min

    Heating power

    3.2KW

    Automatic temperature control

    Max.400℃

    Gross power

    3.45 KW

    Maximum overall dimensions

    2000×1500×1100mm

    Weight

    200Kg

    Power

    380V 60HZ

    Working air pressure

    0.4-0.6Mpa



    Machine Processing


    SAINT BEST GROUP  selected each part  carefully , we are strive to quality first when machine  production and test each machine before delivery. So we will provide the best machine for you.Single Side Heated Roller Press Machine for Warm Edge Spacer Insulating Glass,Mimi Heated Roller Press Machine for Warm Edge Spacer Double Glazing,Single Side Heated Roller Press for Warm Edge Spacer IGU.

    Single Side Cold Press Table for Super Spacer Insulating Glass / Double Glazing

    Qualit Control

    SAINT BEST GROUP engineers have years of experience in window machine fabrication, which makes the precision and stability better than others.

    After machine production finished, the products will be tested in professional ways make sure its performance.Mini Heated Roller Press for Warm Edge Spacer DGU,Single Side Insulating Glass Heated Roller Press,Single Side Double Glazing Heated Roller Press,Mini Hot Roller Press,Mini Heated Roller Press,Mini Triple IGU Heated Roller Press,Mini Triple Insulating Glass Heated Roller Press,Single Side Triple Glazed Heated Roller Press.



    Packaging & Shipping


    SAINT BEST GROUP produce high quality machines, also pay attention to package.

    The machines will be packed with steel pallet and standard export wooden case,

    to make sure customer will receive the machines they ordered Intact.Mini Warm Edge Spacer IGU Heated Roller Press,Single Side Warm Edge Spacer DGU Heated Roller Press,Mini Flexible Spacer DGU Hot Roller Press,Single Side Thermocompressor for Insulated Glass,Mini Thermocompressor for Double Glass.

    Single Side Cold Press Table for Super Spacer Insulating Glass / Double GlazingSingle Side Cold Press Table for Super Spacer Insulating Glass / Double Glazing

    Our Services

    Before Sale:

    Free contact for the most suitable machine

    Free professional design for each customer especially.



    After sale service :

    24 hours technical support by phone, email or skype (email or skype) .

    1years  warranty period

    Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.

    By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.



    Payment Terms :

    ♦ T/T, 30% deposit by T/T,70% spare payment before shipment.

    ♦ Western Union or Paypal



    A,12month warranty

    B,1%-2% spare parts

    C, OEM&ODM are welcomed

    D,Trail orders are available

    Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.

    By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.Mini Thermocompressor for Triple Glazing Glass,Single Side Flexible Spacer Double Glass Hot Roller Press,Single Side Warm Edge Spacer Hollow Glass Hot Roller Press.

    Saint Best Group always looking for long term cooperaion, not one time deal

    Our Advantage:

    Our company owns excellent team of research and development and technician which lay foundation of high-quality machine. We use are imported components and after machine production finished, the products will be tested in professional ways make sure its performance.Mini Warm Edge Spacer Hollow Glass Heated Roller Press Machine,Mini Warm Edge Spacer Glass Heated Roller Press,MINI Hot Roller Press Machine,Single Side Insulating Glass Hot Roller Press,MINI Double Glazing Hot Press Machine,Single Side Heated Press for Insulating Glass,MINI Heated Press for Double Glazing.



    Cooperative  Partners

    Single Side Cold Press Table for Super Spacer Insulating Glass / Double Glazing

    FAQ

     1. Question:Are you manufacture?

    Answer:

    Yes,we are the professional manufacture which have more than 5 workshops.

     2.Question: About this Machine,What’s the guarantee ?

    Answer:

    1).Our guarantee for 12 months.

     2).24 hour’s technical support by email or calling

    3).English manual and video tutorial

    4).We will provide the consumable parts at an agency price

    5).24 hours on line service each day, free technical support.

    3.Question:Why your price is higher than another company or factories ?

    Answer: please check, what is is the differences of the machine of  parts ,service and guarantee,especially the machine inner electric parts.MINI Warm Edge Spacer Hollow Glass Heated Roller Press Machine,Mini Warm Edge Spacer Glass Heated Roller Press,Single Side Hot Roller Press Machine,MINI Insulating Glass Hot Roller Press,MINI Double Glazing Hot Press Machine,Single Side Heated Press for Insulating Glass,Single Side Heated Press for Double Glazing,Hot Press Table,Heated Press Table.

    Single Side Cold Press Table for Super Spacer Insulating Glass / Double GlazingSingle Side Cold Press Table for Super Spacer Insulating Glass / Double GlazingSingle Side Cold Press Table for Super Spacer Insulating Glass / Double Glazing
