    Product Details:

    Place of Origin: China
    Brand Name: Saint Best
    Certification: Valid
    Model Number: SBT-CNC-3826AL/4028AL

    Payment & Shipping Terms:

    Minimum Order Quantity: 1Set
    Price: Negotiable
    Packaging Details: Customized
    Delivery Time: 15days
    Payment Terms: T/T
    Supply Ability: 28Sets/Month
    Contact Now
    Detailed Product Description

    CNC Automatic Glass Cutting Table with Automatic Glass Loading



    Product Details:



    Place of Origin: China
    Brand Name: Saint Best
    Certification: CE
    Model Number: SBT-CNC-3826AL

    Payment & Shipping Terms:



    Minimum Order Quantity: 1 Set
    Price: Negotiable
    Packaging Details: Standard Export Package/Wooden Crate
    Delivery Time: 20~40Days
    Payment Terms: T/T, Western Union, MoneyGram,Paypal,Alipay
    Supply Ability: 18Sets/Month
    Detailed Product Description



    Machine: CNC Automatic Shaped Glass Cutting Machine With Semi-Automatic Glass Loading Model: SBT-CNC-3826SL
    Control System: CNC Glass Cut: Shape Glass Cutting
    Max. Speed: 160m/Min Max Size: 3700x2500mm
    Servo Motor: Yaskawa Rack: Altantic Germany
    Valve: SMC Sensor: Panasonic
    Glass Thickness: 2~19mm




    CNC Automatic  Glass Cutting Machine with Automatic Loading 3700x2500mm

    CNC Automatic Shaped Glass Cutting Machine with Semi-Automatic Glass Loading

    CNC Glass Cutting Table /  Automatic Glass Cutting Line

    Automatic Glass Cutting Machine /  CNC Glass Cutting Line

     CNC  Automatic Shaped Glass  Cutting Machine for Pentagon / Ploygon Glass Cutting

    CNC   Glass  Cutting Machine for Triangle  / Trapezium  / Straight Edge+Simicircle Glass Cutting

    CNC Automatic Shape Glass Cutting Table 3700x2500mm

    Automatic CNC Glass Cutting Line

    CNC Glass Cutting Machine

    Quick Details

    • Condition: New
    • Machine Type: Glass Cutting Machine
    • Production Capacity: 160m/min
    • Place of Origin:  China (Mainland)
    • Brand Name: SAINT BEST
    • Model Number: SBT-CNC-3826AL
    • Voltage: 380V/50Hz/3phase
    • Certification: CE
    • Warranty: 1year
    • After-sales Service Provided: Engineers available to service machinery overseas
    • Glass Cut: Any Shape
    • Max. Speed: 160m/Min
    • Servo Motor: Yaskawa
    • Rack: Altantic Germany
    • Valve: SMC
    • Sensor: Panasonic
    • Maximum glass size: 3700x2500mm
    • Glass thickness: 2~19mm

    Packaging & Delivery

    Packaging Details: Standard Export Package/Wooden Crate
    Delivery Detail: 20-40days




    SBT-CNC-3826AL CNC Automatic Shaped Glass Cutting Machine with Automatic Glass Loading





    Characteristic

    -          Mn bridge steel (Q345A ), perfect surface treatment

    -          Optimized table structure makes sure the stable table, dynamic balance and mechanics intensity perfectly matched

    -          Cutting pressure automatic adjusted according to glass thickness

    -          Cutter head 360 degree rotating

    -          Climbing wheels on the cutter head for protecting the cutter assembly and the glass

    -          Water proof surface panel, stainless steel side covered, water and deformation resisting

    -          High quality felt, perfect level, anti-static

    -          Automatic side locating system, pneumatic mechanical and photoelectric joint locating

    -          Self-lubricating guide rail

    -          Air filter for keeping the oil clean

    -          Air float and belt transmit

    -          Linear guide rail

    -          Automatic oiling for transmission system



    Mechanical Parts



    Name

    Brand

    Table surface panel

    High-density waterproof panel, roughness≤±0.20mm/m (Imported material)

    Rack and rail

    ALTANTA GEMERGY

    Belt/band pulley

    KONYEAR

    Cutter wheels and holder

    BOHLE GEMANY



    Electric Parts:



    Name

    Brand

    Touch screen

    LG KOREA

    Relay

    OMRON JAPAN

    Terminal

    WAGO GERMANY

    Air-break switch/low-voltage apparatus/button

    MOELLER GERMANY

    Servo motor

    YASKAWA JAPAN

    Proportioning solenoid valve

    SMC JAPAN

    A.C. contactor

    SCHNERDER

    Laser Sensor

    PANASONIC

    Position switch

    OMRON

    Control card

    NAIKA (GERMANY)/GALIL(USA)

    Frequency converter

    DELTA

    Pneumatic components

    AIRTAC





    Technical Parameter:

    Model

    Max. Glass size

    Thickness

    Max. Speed

    Air Pressure

    SBT-CNC-2620

    2440*1830mm

    2~19mm

    150m/min

    0.6~0.8MPa

    SBT-CNC-3826

    3700*2500mm

    3~19mm

    160m/min

    0.6~0.8MPa

    SBT-CNC-4028

    4000*2800mm

    3~19mm

    160m/min

    0.6~0.8MPa


    Machine Processing

    SAINT BEST GROUP  selected each part  carefully , we are strive to quality first when machine  production and test each machine before delivery.  So we will provide the best machine for you.Automatic Glass Shape Cutting Machine With Semi-Automatic Loading Device,Automatic Glass Shape Cutting Machine,Automatic CNC Shaped Glass Cutting Machine,Shaped Glass Cutting Machine,CNC Shaped Glass Cutting Machine,Automatic Glass Cutting Machine.

    380V/50Hz CNC Automatic Glass Cutting Table with Automatic Glass Loading

    Qualit Control

    SAINT BEST GROUP engineers have years of experience in window machine fabrication, which makes the precision and stability better than others.

    After machine production finished, the products will be tested in professional ways make sure its performance.



    Packaging & Shipping


    SAINT BEST GROUP produce high quality machines, also pay attention to package.

    The machines will be packed with steel pallet and standard export wooden case,

    to make sure customer will receive the machines they ordered Intact.

    380V/50Hz CNC Automatic Glass Cutting Table with Automatic Glass Loading

    Our Services

    Before Sale:

    Free contact for the most suitable machine

    Free professional design for each customer especially.



    After sale service :

    24 hours technical support by phone, email or skype (email or skype) .

    1years  warranty period

    Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.

    By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.



    Payment Terms :

    ♦ T/T, 30% deposit by T/T,70% spare payment before shipment.

    ♦ Western Union or Paypal



    A,12month warranty

    B,1%-2% spare parts

    C, OEM&ODM are welcomed

    D,Trail orders are available

    Our senior engineer is available to travel aboard, help the installation, maintenance and training staff.

    By offering this support, we make sure the cutomer start the business smoothly, to realise win-win cooperation.

    Saint Best Group always looking for long term cooperaion, not one time deal.



    Our Advantage:

    Our company owns excellent team of research and development and technician which lay foundation of high-quality machine. We use are imported components and after machine production finished, the products will be tested in professional ways make sure its performance.CNC Glass Cutting Machine,Automatic Glass Loading Machine,Automatic Glass Shape Cutting Line,Automatic CNC Shaped Glass Cutting Line,Shaped Glass Cutting Line,CNC Shaped Glass Cutting Line.CNC Automatic Shaped Glass Cutting Machine with Semi-Automatic Glass Loading

    Cooperative  Partners

    380V/50Hz CNC Automatic Glass Cutting Table with Automatic Glass Loading

    FAQ

     1. Question:Are you manufacture?

    Answer:

    Yes,we are the professional manufacture which have more than 5 workshops.

     2.Question: About this Machine,What’s the guarantee ?

    Answer:

    1).Our guarantee for 12 months.

     2).24 hour’s technical support by email or calling

    3).English manual and video tutorial

    4).We will provide the consumable parts at an agency price

    5).24 hours on line service each day, free technical support.

    3.Question:Why your price is higher than another company or factories ?

    Answer: please check, what is is the differences of the machine of  parts ,service and guarantee,especially the machine inner electric parts,

    sometimes,if the machine have breakdown, the most reason is the machine inner electric parts problem,

    but we use the famous and reliable parts for the machines inside.



    380V/50Hz CNC Automatic Glass Cutting Table with Automatic Glass Loading
